AC Power 2 Cylinders R22 Cold Storage Compressor Blue Color
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Refrigerant | R22 | Color | Blue |
|---|---|---|---|
| Cylinder Nos | 2 | Weight(kg) | 35 |
| Warranty | 1 Year | Power Source | AC Power |
| High Light | 2 Cylinders Cold Storage Compressor,Blue Color Cold Storage Compressor,AC Power Cold Storage Compressor |
||
Product Description
100% New and origin Made in CHINA R22 Maneurop Compressor Model MT44
| MT044-4. Cooling capacity [kW] | ||||||||||||
| Tc/Te | -25.0 | -20.0 | -15.0 | -10.0 | -5.0 | 0 | 5.0 | 10.0 | 15.0 | |||
| 30.0 | 2.499 | 3.543 | 4.855 | 6.462 | 8.389 | 10.66 | 13.31 | 16.35 | 19.81 | |||
| 35.0 | 2.234 | 3.195 | 4.412 | 5.913 | 7.722 | 9.865 | 12.37 | 15.26 | 18.56 | |||
| 40.0 | 1.995 | 2.868 | 3.987 | 5.377 | 7.065 | 9.075 | 11.43 | 14.17 | 17.30 | |||
| 45.0 | 1.788 | 2.570 | 3.586 | 4.862 | 6.423 | 8.296 | 10.51 | 13.08 | 16.04 | |||
| 50.0 | 2.306 | 3.215 | 4.372 | 5.804 | 7.536 | 9.593 | 12.00 | 14.79 | ||||
| 55.0 | 2.880 | 3.915 | 5.213 | 6.799 | 8.700 | 10.94 | 13.55 | |||||
| 60.0 | 3.496 | 4.656 | 6.093 | 7.832 | 9.900 | 12.32 | ||||||
| 65.0 | 4.140 | 5.423 | 6.998 | 8.889 | 11.12 | |||||||
| MT044-4. Power consumption [kW] | ||||||||||||
| Tc/Te | -25.0 | -20.0 | -15.0 | -10.0 | -5.0 | 0 | 5.0 | 10.0 | 15.0 | |||
| 30.0 | 1.611 | 1.799 | 1.969 | 2.120 | 2.251 | 2.362 | 2.451 | 2.519 | 2.564 | |||
| 35.0 | 1.655 | 1.868 | 2.064 | 2.242 | 2.401 | 2.540 | 2.659 | 2.758 | 2.834 | |||
| 40.0 | 1.684 | 1.924 | 2.148 | 2.355 | 2.544 | 2.714 | 2.865 | 2.996 | 3.106 | |||
| 45.0 | 1.695 | 1.965 | 2.219 | 2.457 | 2.678 | 2.881 | 3.066 | 3.232 | 3.378 | |||
| 50.0 | 1.988 | 2.275 | 2.546 | 2.801 | 3.039 | 3.260 | 3.463 | 3.647 | ||||
| 55.0 | 2.313 | 2.619 | 2.911 | 3.187 | 3.446 | 3.688 | 3.912 | |||||
| 60.0 | 2.675 | 3.005 | 3.320 | 3.620 | 3.903 | 4.170 | ||||||
| 65.0 | 3.082 | 3.438 | 3.781 | 4.108 | 4.418 | |||||||
| MT044-4. Heating capacity [kW] | ||||||||||||
| Tc/Te | -25.0 | -20.0 | -15.0 | -10.0 | -5.0 | 0 | 5.0 | 10.0 | 15.0 | |||
| 30.0 | 3.759 | 5.076 | 6.644 | 8.467 | 10.55 | 12. 91 | 15.57 | 18.54 | 21.85 | |||
| 35.0 | 3.485 | 4.741 | 6.244 | 8.000 | 10.02 | 12.31 | 14.88 | 17.77 | 21.00 | |||
| 40.0 | 3.235 | 4.419 | 5.849 | 7.531 | 9.472 | 11.68 | 14.18 | 16.98 | 20.12 | |||
| 45.0 | 3.024 | 4.121 | 5.467 | 7.066 | 8.923 | 11.05 | 13.46 | 16.17 | 19.22 | |||
| 50.0 | 3.862 | 5.110 | 6.613 | 8.378 | 10.41 | 12.73 | 15.35 | 18.30 | ||||
| 55.0 | 4.789 | 6.184 | 7.844 | 9.776 | 11.99 | 14.51 | 17.36 | |||||
| 60.0 | 5.790 | 7.331 | 9.151 | 11.26 | 13.67 | 16.41 | ||||||
| 65.0 | 6.852 | 8.544 | 10.53 | 12.83 | 15.46 | |||||||
| MT044-4. Current [A] | ||||||||||||
| Tc/Te | -25.0 | -20.0 | -15.0 | -10.0 | -5.0 | 0 | 5.0 | 10.0 | 15.0 | |||
| 30.0 | 4.116 | 4.291 | 4.474 | 4.656 | 4.828 | 4.979 | 5.102 | 5.185 | 5.221 | |||
| 35.0 | 4.173 | 4.367 | 4.572 | 4.776 | 4.972 | 5.150 | 5.300 | 5.413 | 5.479 | |||
| 40.0 | 4.213 | 4.434 | 4.666 | 4.900 | 5.128 | 5.338 | 5.523 | 5.673 | 5.778 | |||
| 45.0 | 4.227 | 4.481 | 4.749 | 5.020 | 5.286 | 5.537 | 5.764 | 5.958 | 6.108 | |||
| 50.0 | 4.502 | 4.812 | 5.127 | 5.439 | 5.738 | 6.014 | 6.258 | 6.461 | ||||
| 55.0 | 4.846 | 5.213 | 5.578 | 5.931 | 6.264 | 6.566 | 6.829 | |||||
| 60.0 | 5.269 | 5.694 | 6.109 | 6.505 | 6.872 | 7.202 | ||||||
| 65.0 | 5.779 | 6.263 | 6.729 | 7.169 | 7.573 | |||||||
| MT044-4. COP [W/W] | |||||||||||
| Tc/Te | -25.0 | -20.0 | -15.0 | -10.0 | -5.0 | 0 | 5.0 | 10.0 | 15.0 | ||
| 30.0 | 1.55 | 1.97 | 2.47 | 3.05 | 3.73 | 4.51 | 5.43 | 6.49 | 7.73 | ||
| 35.0 | 1.35 | 1.71 | 2.14 | 2.64 | 3.22 | 3.88 | 4.65 | 5.53 | 6.55 | ||
| 40.0 | 1.19 | 1.49 | 1.86 | 2.28 | 2.78 | 3.34 | 3.99 | 4.73 | 5.57 | ||
| 45.0 | 1.05 | 1.31 | 1.62 | 1.98 | 2.40 | 2.88 | 3.43 | 4.05 | 4.75 | ||
| 50.0 | 1.16 | 1.41 | 1.72 | 2.07 | 2.48 | 2.94 | 3.46 | 4.05 | |||
| 55.0 | 1.25 | 1.50 | 1.79 | 2.13 | 2.52 | 2.97 | 3.46 | ||||
| 60.0 | 1.31 | 1.55 | 1.83 | 2.16 | 2.54 | 2.96 | |||||
| 65.0 | 1.34 | 1.58 | 1.85 | 2.16 | 2.52 | ||||||
| MT044-4. Mass flow [kg/h] | ||||||||||||
| Tc/Te | -25.0 | -20.0 | -15.0 | -10.0 | -5.0 | 0 | 5.0 | 10.0 | 15.0 | |||
| 30.0 | 54.43 | 76.11 | 102.9 | 135.2 | 173.4 | 217.8 | 268.8 | 326.7 | 392.0 | |||
| 35.0 | 50.63 | 71.36 | 97.21 | 128.5 | 165.8 | 209.2 | 259.2 | 316.3 | 380.7 | |||
| 40.0 | 47.15 | 66.78 | 91.51 | 121.7 | 157.8 | 200.2 | 249.1 | 305.2 | 368.6 | |||
| 45.0 | 44.20 | 62.54 | 85.96 | 114.9 | 149.7 | 190.8 | 238.6 | 293.5 | 355.8 | |||
| 50.0 | 58.83 | 80.74 | 108.2 | 141.5 | 181.2 | 227.7 | 281.3 | 342.5 | ||||
| 55.0 | 76.07 | 101.8 | 133.5 | 171.6 | 216.5 | 268.7 | 328.6 | |||||
| 60.0 | 95.90 | 125.7 | 162.0 | 205.2 | 255.8 | 314.2 | ||||||
| 65.0 | 118.4 | 152.6 | 193.9 | 242.7 | 299.6 | |||||||
Te = Evaporating temperature [°C]
Tc = Condensing temperature [°C]
