SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication

  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
  • SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication
Place of Origin Shanghai, China
Brand Name Famous
Certification CE
Model Number SZ161T4VC
Minimum Order Quantity 1
Packaging Details Pallet packaging
Delivery Time 7
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000 Piece/Pieces per Year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New After Warranty Service Online Support
Showroom Location None Machinery Test Report Not Available
Place Of Origin Tianjin, China Type Refrigeration Compressor, Scroll
Warranty 1 Year Lubrication Style Oil-less
Product Name Refrigeration Compressor Applicable Industries Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Local Service Location None Video Outgoing-inspection Provided
Marketing Type Ordinary Product Brand Name Famous
Application Refrigeration Parts After-sales Service Provided Online Support, Online Support
Packing Wooden Case MOQ 1
High Light

R407C Cold Storage Compressor

,

SZ161T4VC Cold Storage Compressor

,

Cold Storage Compressor 13HP
Leave a Message
Product Description

SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication

Name Reciprocating Compressors
model SZ161T4VC
Nominal cooling capacity at 50Hz 33.9KW
refrigerant R134A/R404/R407c
Voltage 380/50HZ
Color Blue
Connection Rotolock
TYPE SCROLL COMPRESSOR

SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 0

SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 1

SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 2





SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 3









cooling capacity(kw)
Tc/Te -15 -10 -5 0 5 10 15
30 11.72 14.9o 18.69 23.18 28.43 34.54 41.57
35 11.08 14.15 17.8 22.11 27.15 33.02 39.78
40 10.42 13.37 16.86 20.98 25.81 31.43 37.91
45 9.742 12.56 15.89 19.82 24.42 29.77 35.96
50 9.049 11.72 14.88 18.61 22.97 28.06 33.95
55 　 10.87 13.85 17.36 21.48 26.29 31.87
60 　 　 12.8 16.09 19.95 24.47 29.73
65 　 　 　 14.79 18.39 22.61 27.54
70 　 　 　 13.47 16.8 20.71 25.3



power consumption(kw)
Tc/Te -15 -10 -5 0 5 10 15
30 4.657 4.702 4.744 4.784 4.821 4.855 4.885
35 5.178 5.229 5.274 5.315 5.351 5.381 5.406
40 5.752 5.808 5.857 5.898 5.933 5.961 5.98
45 6.389 6.45 6.502 6.545 6.579 6.603 6.618
50 7.1 7.166 7.222 7.266 7.299 7.32 7.33
55 　 7.968 8.027 8.072 8.104 8.123 8.127
60 　 　 8.927 8.974 9.006 9.021 9.02
65 　 　 　 9.983 10.01 10.03 10.02
70 　 　 　 11.11 11.14 11.15 11.14



Heating capacity(kw)
Tc/Te -15 -10 -5 0 5 10 15
30 16.38 19.6 23.44 27.96 33.25 39.39 46.45
35 16.26 19.38 23.07 27.42 32.5 38.4 45.18
40 16.17 19.17 22.72 26.88 31.73 37.39 43.89
45 16.13 19.01 22.39 26.36 31 36.38 42.58
50 16.15 18.89 22.11 25.87 30.27 35.35 41.27
55 　 18.84 21.88 25.44 29.59 34.38 39.99
60 　 　 21.73 25.06 28.96 33.5 38.72
65 　 　 　 24.77 28.4 32.64 37.51
70 　 　 　 24.58 27.93 31.86 36.4



Current [A]
Tc/Te -15 -10 -5 0 5 10 15
30 12.58 12.6 12.6 12.59 12.58 12.59 12.62
35 13.01 13.05 13.06 13.05 13.05 13.05 13.08
40 13.52 13.57 13.59 13.59 13.59 13.6 13.63
45 14.13 14.19 14.22 14.23 14.23 14.24 14.27
50 14.85 14.92 14.96 14.98 14.99 15 15.03
55 　 15.78 15.84 15.86 15.88 15.89 15.92
60 　 　 16.86 16.9 16.92 16.94 16.97
65 　 　 　 18.1 18.12 18.15 18.18
70 　 　 　 19.48 19.52 19.54 19.58



cop(w/w)
Tc/Te -15 -10 -5 0 5 10 15
30 2.52 3.17 3.94 4.84 5.9 7.11 8.51
35 2.14 2.71 3.37 4.16 5.08 6.14 7.36
40 1.81 2.3 2.88 3.56 4.35 5.27 6.34
45 1.53 1.95 2.44 3.03 3.71 4.51 5.43
50 1.28 1.64 2.06 2.56 3.15 3.83 4.63
55 　 1.36 1.73 2.15 2.65 3.24 3.92
60 　 　 1.43 1.79 2.22 2.71 3.3
65 　 　 　 1.48 1.84 2.26 2.75
70 　 　 　 1.21 1.51 1.86 2.27



Mass flow [kg/h]
Tc/Te -15 -10 -5 0 5 10 15
30 271.3 337.7 415.2 504.8 607.6 724.7 856.9
35 269.3 336.3 414.2 504 606.9 723.9 856.1
40 266.7 334.2 412.3 502.2 605 721.9 854
45 263.5 331.4 409.7 499.5 602.1 718.8 850.6
50 259.9 328.1 406.2 495.8 598.1 714.4 845.9
55 　 324.2 402.2 491.3 593.1 708.9 839.9
60 　 　 397.5 486.1 587.2 702.3 832.7
65 　 　 　 480.2 580.5 694.8 824.5
70 　 　 　 474 573.3 686.6 815.6



SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 4



SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 5SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 6SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 7SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 8SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 9SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 10SZ161T4VC R407C Cold Storage Compressor 13HP Oilless Lubrication 11
