Tecumseh CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems for low temperature

Place of Origin Shanghai, China (Mainland)
Brand Name KUB
Certification CE
Model Number CAJ2446z
Minimum Order Quantity 1 Set/Sets
Price US $1418 / Sets | 1 Set/Sets (Min. Order)
Packaging Details plywood package
Delivery Time 5-10days
Payment Terms L/C, T/T, Western Union
Supply Ability 100 sets per week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Compressor Brand Tecumseh Application Cold Storage Room Freezer Room
First Stage R404a Temperature 0~-75℃
Second Stage R23 Voltage 220V 1PH 50HZ
High Light

commercial refrigerator condenser

,

fridge condensing unit

Leave a Message
Product Description

This CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems, which is suitable for low temperature refrigeration at 0~-75℃.



size is  620*580*300mm



Tecumseh compressor series First stage R404A Second stage R23 -70℃ refrigeration capacity KW
1HP CAJ2446Z CAJ2446Z 0.3

We provide many different types of cascade units, the following is a partial list of models:



Tecumseh compressor series First stage R404A Second stage R23 -70℃ refrigeration capacity KW
1HP CAJ2446Z CAJ2446Z 0.3
1.5HP CAJ2464Z CAJ2464Z 0.5
3HP TFH2511Z TFH2511Z 1
4HP TAG2516Z TAG2516Z 1.4
6HP TAG2522Z TAG2522Z 2
Hangzhou Compressor Series
8HP 4YD10Y 4YD8Y 4.5
10HP 4YD12Y 4YD10Y 5
12HP 4YD15Y 4YD12Y 6.1
15HP box&V type 4YD20Y 4YD15Y 9.2
20HP 4VD20Y 4VD20Y 10.5
25HP 6VD25Y 6VD25Y 13.4
30HP 6WD30Y 6WD30Y 15
40HP 6WD40Y 6WD40Y 17.5

The cascade refrigeration cycle is mainly composed of two complete refrigeration systems, a high-temperature part and a low-temperature part. Among them, the evaporator of the high temperature part is the condenser of the low temperature part, so it is called the evaporative condenser, and the rest is basically the same as the general refrigeration device.



Tecumseh CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems for low temperature 0



Tecumseh CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems for low temperature 1



The following is the default configuration list of this unit. We have taken into account the safety and efficiency of operation. The actual refrigeration device can add some auxiliary equipment, such as filter drier, solenoid valve, regenerator, oil separator, etc.

(1) Filter drier: It can remove the moisture and impurities in the liquid refrigerant from the condenser, and prevent the formation of ice blockage and dirty blockage at the expansion valve or filter drier.

(2) Solenoid valve: It automatically cuts off the liquid supply to prevent excessive refrigerant from entering the evaporator after shutdown, so as to avoid wet stroke or liquid shock when the machine is turned on next time.

(3) Regenerator: heat exchange between the supply liquid and the return air, supercool the liquid refrigerant, increase the refrigeration capacity per unit mass, and at the same time increase the superheat of the return air to prevent the wet stroke and liquid hammer of the compressor.

(4) Oil separator: Separate the lubricating oil from the compressor exhaust and return it to the crankcase to prevent the oil from entering the heat exchanger and affecting the heat transfer efficiency, while ensuring the lubrication of the compressor.





Air-cooled cascade unit assembly list
Name Brand Model
Tecumseh CAJ2446Z
8+2 Dual system condenser Made in china
Motor   300
4L Expansion tank Made in china 4L
083S Filter KUB KUB-083S
Oil separator KUB AW55824
Solenoid valves Hong Sen SV68-3
Plate heat exchanger ZL14-40 Made in china ZL14-40
Expansion valve TS2 Danfoss TS2
Unloading valve   23KG



Tecumseh CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems for low temperature 2



Tecumseh CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems for low temperature 3

Tecumseh CAJ2446z cascade refrigeration unit is a combination of two refrigeration systems for low temperature 4
