Oem Odm Compressor Condenser Unit , Commercial Condensing Unit Long Service Life

Place of Origin Shanghai, China (Mainland)
Brand Name KUB
Certification CE
Model Number KUB1000UL
Minimum Order Quantity 1 Set/Sets
Price negotiable
Packaging Details Plywood pallet+Plywood
Supply Ability 50 units per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type U Type Refrigeration Unit Compresor Brand /Copeland/Carlyle/Carrier/Emerson/
Shell Material Stainless Steel S304L Application Food Factory, Processing Factory,
Power 380V/3Ph/50Hz Custom Made OEM
High Light

commercial refrigerator condenser

,

fridge condensing unit

Leave a Message
Product Description

10HP 10 ton r404a 4PES-12Y U type Corrosion-resistant stainless steel refrigeration unit for food processing



semi-hermetic Reciprocating compressor for Medium and low temperature R404a  Nominal data



Application limits



R134a, R407A, R407C



R407F, R404A/R507A



R22



has always paid special attention to the efficiency of compressors and a few years ago introduced the ECOLINE series, which has been optimized especially for R134a.R134a offers very favorable characteristics especially for medium temperature and heat pump applications. This includes the extra high efficiency, moderate pressure levels (reduced leakage rates) and the lowest GWP value of all non-flammable HFC refrigerants. This gives the ECOLINE compressors, which can also be used at very low condensing temperatures, a beneficial seasonal energy efficiency beyond comparison. Studies have demonstrated that for supermarket applications a hybrid version with R134a for medium temperature application in cascade with CO2 low temperature application offers a particularly advantageous ecological efficiency (optimum of life cycle costs
and TEWI) as well as a low energy demand.







HP Compressor

Condenser

Surface

M2

Voltage Cooling capacity(W) Axial Fans
(V-Ph-Hz) Evaporating temperature(°C)
-35 -30 -25 -20 -15 N°x Diameter
2 2FES-2Y 16 380-3-50 1000 1420 1910 2480 3140 1 x 350
2 2EES-2Y 16 380-3-50 1280 1820 2450 3190 4050 1 x 400
2 2DES-2Y 16 380-3-50 1600 2240 2990 3870 4890 1 x 400
3 2CES-3Y 24 380-3-50 2110 2890 3810 4880 6120 2 x 350
3 4FES-3Y 24 380-3-50 2380 3170 4120 5250 6580 2 x 350
4 4EES-4Y 32 380-3-50 3010 4020 5240 6690 8390 2 x 400
5 4DES-5Y 40 380-3-50 3600 4800 6260 8000 10040 2 x 400
6 4CES-6Y 48 380-3-50 4220 5690 7480 9610 12120 2 x 400
8 4TES-9Y 64 380-3-50 4840 6740 9030 11780 15040 2 x 450
10 4PES-12Y 80 380-3-50 5040 7200 9830 13010 16790 2 x 450
12 4NES-14Y 96 380-3-50 6580 9140 12240 15950 20350 4 x 400
15 4HE-18Y 120 380-3-50 10070 13570 17720 22600 28350 4 x 400
20 4GE-23Y 160 380-3-50 12320 16290 21000 26550 33050 4 x 400
25 6HE-28Y 200 380-3-50 14800 19970 26100 33300 41750 4 x 400
30 6GE-34Y 240 380-3-50 18920 24850 31800 39950 49400 2 x 600
40 6FE-44Y 320 380-3-50 21900 29250 37750 47650 59100 2 x 600




Oem Odm Compressor Condenser Unit , Commercial Condensing Unit Long Service Life 0

Oem Odm Compressor Condenser Unit , Commercial Condensing Unit Long Service Life 1

-20~+45℃ Intelligent Integrate Commercial Refrigeration Condensing Units 3HP R404a For Cold Room Storage KB030RLE 3
