Mt36 Mtz36 Small Condensing Unit , Commercial Condensing Unit High Control Accuracy
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Temperature | -15~-20℃ | Voltage | 380V/3P/50Hz |
|---|---|---|---|
| HS Code | 84186920 | Horse Power | 3HP |
| High Light | freezer condenser unit,carrier condensing unit |
||
Product Description
MT36 MTZ36 Maneurop compressor Condensing Units
Maneurop Compressor Condensing Unit
Features:
1, Control accuracy, safety, reliability, little vibration, convenient installation and beautiful appearance;
2, All the accessories are world famous brand, which with reliable quality;
3, Flexible combination of capacity, you can start grading, multi-level unload to reduce energy consumption
Information:
1. Applied room temperature -40C~-15C
2. Cooling capacity 2.2.0Kw~14.6Kw
3. Evaporating temperature -50C~-25C
4. Refrigerant: R22, R134a, R404a, R507a
5. Standard Equipment: Compressor, oil pressure safety switch, air-cooled condenser, receiving tank, drier-filter, meter panel, pressure controller, efrigeration oil, protection gas,
P.F refrigeration capacity(kw) TE evaporative temperature(oC)
P.A Iinput power(kw) TC condensing temperature(oC)
Rated condition 50HZ , degree of superheat 11.1 k degree of super-cooling 8.3k
MGM series hermetic condensing units use /Maneurope hermetic compressors,with 1.5HP--13HP rate of power,suitable for all kinds of fresh keeping and freezing cold storages.
Features:
With Copeland scroll or /Maneurope hermetic compressors.
With high efficient and long life copper-aluminum fin heat exchanger.
With high efficient and low noise external rotator fan.
With high quality refrigeration components.
| Item | Reciprocating hermetric compressor |
| Model | MTZ36 |
| Brand | famous brand |
| Power | 50Hz 380V |
| Lubricated style | oil-less |
| Package | 8pcs/pallet |
| Certification | CE |
| Application | Air conditioning, HVAC system |
ell Compressor all models
1,MTZ18,MTZ22,MTZ28,MTZ32,MTZ36
2,MT,MTZ series
3,SH,SY,SZ,SM series
4,MTM,MTZ,LTZ tandem
1,MTZ18,MTZ22,MTZ28,MTZ32,MTZ36
2,MT,MTZ series
3,SH,SY,SZ,SM series
4,MTM,MTZ,LTZ tandem
Type: Hermetic piston compressors
Producer: -Maneurop
Series: MTZ
Model: MTZ36
Technical data
| Cylinder count: | 1 | |
| Displacement [m³/h]: | 10,52 | |
| Cylinder capacity [cm³]: | 60,5 | |
| RPM [min-1]: | 2900 | |
| Weight [kg]: | 25 | |
| Oil charge [dm³]: | 1 | |
| Oil type: | 160PZ | |
| Crankcase heater type: | PTC 35 W | |
| Maximum system test pressure low side / high side: | 25 / 30 | |
| Maximum number of starts without softstart [1/h]: | 12 | |
| Refrigerant charge limit [dm³]: | 3 | |
| Refrigerant: | R134a, 404A/R507, R407C | |
| Sound power [dB]: | 70 | |
| Sound power with accoustic hood [dB]: | 64 |
Connections
| inches | |||
| Suction Rotolock valve connection: | 1 1/4" | ||
| Discharge Rotolock valve connection: | 1" | ||
| Suction connection with supplied sleeve: | 5/8" | ||
| Discharge connection with supplied sleeve: | 1/2" |
Approvals
| CCC | + | |
| CE | + | |
| UL | + |
Standard equipment
- rubber vibration absorbers
- oil sight glass
- oil equalization
Optional equipment
- crankcase heater
- belt type heater
- Rotalock valves
- soft-start kit
- accoustic hood
Application
- high and medium evaporating temperatures
(R134a from 20 ºC to -15 ºC)
(R404A/R507 from 10 ºC to -30 ºC)
(R407C from 15 ºC to -15 ºC)
Capacity: R134a, 404A/R507, R407C
We can supply more compressor models as below:
| MODEL (R22) | MODEL (R404A) | NTZ series |
| MT18-4VM | MTZ18-4VM | NTZ048A4LR1A |
| MT22-4VM | MTZ22-4VM | NTZ068A4LR1A |
| MT28-4VM | MTZ28-4VM | NTZ096A4LR1A |
| MT32-4VM | MTZ32-4VM | NTZ108A4LR1A |
| MT36-4VM | MTZ36-4VM | NTZ136A4LR1A |
| MT40-4VM | MTZ40-4VM | NTZ215A4LR1A |
| MT44-4VM | MTZ44-4VM | NTZ271A4LR1A |
| MT50-4VM | MTZ50-4VM | |
| MT56-4VM | MTZ56-4VM | |
| MT64-4VM | MTZ64-4VM | |
| MT72-4VM | MTZ72-4VM | |
| MT80-4VM | MTZ80-4VM | |
| MT100-4VM | MTZ100-4VM | |
| MT125-4VM | MTZ125-4VM | |
| MT144-4VM | MTZ144-4VM | |
| MT160-4VM | MTZ160-4VM |
| Model NO. | Nom HP | Displ. Cc/rev | Capacity R404a(w) | |
| -10 | -5 | |||
| MTZ18-4VI | 1.5 | 30.2 | 1580 | 2110 |
| MTZ18-5VI | 1.5 | 30.2 | 1580 | 2110 |
| MTZ22-4VI | 1.8 | 38.12 | 2270 | 2920 |
| MTZ22-5VI | 1.8 | 38.12 | 2270 | 2920 |
| MTZ28-4VI | 2.3 | 48.06 | 2880 | 3720 |
| MTZ28-5VI | 2.3 | 48.06 | 2880 | 3720 |
| MTZ32-4VI | 2.7 | 53.86 | 3230 | 4220 |
| MTZ32-5VI | 2.7 | 53.86 | 3230 | 4220 |
| MTZ36-4VI | 3 | 60.47 | 3800 | 4870 |
| MTZ36-5VI | 3 | 60.47 | 3800 | 4870 |
| MTZ40-4VI | 3.3 | 67.89 | 4280 | 5490 |
| MTZ45-4VI | 3.8 | 76.22 | 4420 | 5840 |
| MTZ51-4VI | 4.2 | 85.64 | 5290 | 6920 |
| MTZ57-4VI | 4.8 | 96.13 | 6060 | 7880 |
| MTZ65-4VI | 5.4 | 107.71 | 7080 | 9130 |
| MTZ73-4VI | 6.1 | 120.94 | 7960 | 10230 |
| MTZ81-4VI | 6.8 | 135.78 | 9160 | 11720 |
| MTZ100-4VI | 8.3 | 171.26 | 10390 | 13500 |
| MTZ125-4VI | 10.4 | 215.44 | 13650 | 17500 |
| MTZ144-4VI | 12 | 241.87 | 15740 | 20120 |
| MTZ160-4VI | 13.3 | 271.55 | 17690 | 22520 |
| Code no. | HP | MT-R22 | MTZ-R407C | MTZ-R134a | MTZ-R404 | ||||||||
| Kw | BTUH | EER | Kw | BTUH | EER | Kw | BTUH | EER | Kw | BTUH | EER | ||
| MT/MTZ18 | 1.5 | 1.74 | 15900 | 9.15 | 1.67 | 15300 | 9.13 | 1.22 | 11200 | 9.2 | 1.76 | 10300 | 5.1 |
| MT/MTZ22 | 2 | 2.27 | 22000 | 9.68 | 2.17 | 19600 | 9 | 1.54 | 14800 | 9.63 | 2.05 | 14100 | 6.01 |
| MT/MTZ28 | 2.5 | 3.07 | 30200 | 9.86 | 2.83 | 25100 | 8.9 | 2.04 | 19300 | 9.42 | 2.68 | 18300 | 5.96 |
| MT/MTZ32 | 2.75 | 3.58 | 33000 | 9.22 | 3.21 | 28400 | 8.86 | 2.39 | 20900 | 8.76 | 2.99 | 20100 | 5.85 |
| MT/MTZ36 | 3 | 4.05 | 38000 | 9.38 | 3.75 | 32700 | 8.73 | 2.75 | 24500 | 8.91 | 3.34 | 23200 | 6.05 |
| MT/MTZ40 | 3.5 | 4.63 | 42900 | 9.27 | 4.33 | 37400 | 8.64 | 3.08 | 27900 | 9.03 | 3.77 | 26400 | 6.11 |
| MT/MTZ44 | 4 | 4.67 | 45200 | 9.69 | 4.37 | 43000 | 9.84 | 3.14 | 29800 | 9.51 | 4.18 | 27800 | 6.65 |
| MT/MTZ50 | 4.5 | 5.18 | 50500 | 9.74 | 4.96 | 48100 | 9.71 | 3.6 | 34500 | 9.57 | 4.83 | 32500 | 6.73 |
| MT/MTZ56 | 5 | 6.05 | 56400 | 9.32 | 5.67 | 54300 | 9.59 | 3.95 | 38000 | 9.62 | 5.44 | 36500 | 6.71 |
| MT/MTZ64 | 5.5 | 6.8 | 64800 | 9.53 | 6.36 | 60400 | 9.5 | 4.68 | 45300 | 9.66 | 6.12 | 41500 | 6.78 |
| MT/MTZ72 | 6 | 7.58 | 70100 | 9.26 | 7.22 | 67900 | 9.41 | 5.19 | 50000 | 9.63 | 6.91 | 46500 | 6.72 |
| MT/MTZ80 | 7 | 8.56 | 80000 | 9.35 | 8.24 | 76900 | 9.33 | 6 | 56500 | 9.42 | 8.03 | 52500 | 6.54 |
| MT/MTZ100 | 9 | 9.59 | 95900 | 10 | 9.9 | 94400 | 9.53 | 6.5 | 63900 | 9.84 | 8.72 | 60800 | 6.07 |
| MT/MTZ125 | 10 | 12.81 | 124600 | 9.73 | 12.62 | 122100 | 9.67 | 7.72 | 78900 | 10.2 | 11.37 | 78400 | 6 |
| MT/MTZ144 | 12 | 14.36 | 140700 | 9.8 | 14.47 | 137200 | 9.48 | 9.82 | 96900 | 9.87 | 13 | 92300 | 6.19 |
| MT/MTZ160 | 13.5 | 16.09 | 156800 | 9.75 | 16.67 | 155100 | 9.31 | 10.92 | 107600 | 9.85 | 14.74 | 100300 | 5.93 |
