Air Cooled Compressor Freezer Semi Hermetic Condensing Unit For Meat

Place of Origin Shanghai, China (Mainland)
Brand Name KUB
Certification CE
Minimum Order Quantity 1 Set/Sets
Price negotiable
Packaging Details Plywood pallet+Plywood
Payment Terms L/C, T/T
Supply Ability 50 units per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Condensing Unit Compressor Compressor
Refrigerant R404A Voltage 380V/3Ph/50Hz
Application Cold Storage Room Freezer Room After-sales Service Provided Online Support
Product Name Condensing Unit
High Light

Hermetic Compressor Condensing Unit

,

R404A Cold Storage Condensing Unit

,

Compact Semi Hermetic Condensing Unit

Leave a Message
Product Description

Original Compressor Condensing Unit r404a air cooled condensing units for cold room

More compressor units for your reference
 2GES-2, 2FES-3, 2EES-3, 2DES-3, 2CES-4, 4FES-5, 4EES-6, 4DES-7, 4CES-9, 4VES-10, 4TES-12, 4PES-15, 4NES-20, 4J-22.2, 4HE-25, 4GE-30, 6HE-35
Piston Compressor

1.All models on sale
2.Competitive Price
3.Continuous Supply Capacity

refrigeration compressor features:
A closely graduated product range for modern refrigeration,A/C,and heat pump systems
With the ECOLINE series offers highly efficient all-purpose compressors,which meet the challenging demands of modern refrigeration systems:
Extended application range
R134a up to tc=85℃
R404 and R507 up to tc=62℃
Energy efficient
High cooling capacity minimum energy requirement:
Highly efficient working valves
Minimum clearance volume
Efficient,large-volume motor
Reduced flow losses at low condensing temperatures
Wear resistant drive gear
Surface hardened eccentric shaft and crankshaft
Low friction bearings and aluminium pistons
Hard chrome plated piston rings
Quiet with low vibration
Optimized mass balance
Low discharge gas pulsations due to special cylinder hear design
Minimum space requirement
Very compact design
Robust
Solid valve plate design
Valves made of impact resistant spring steel
Wear resistant drive gear
Efficient capacity control
Cylinder shut-off or VSD capacity control possible
Cylinder shut-off possible from 18 displacement (50HZ) on
-4 cylinder compressor:50%
-6 cylinder compressor:66%/33%
-8 cylinder compressor:75%/50%
Fast cycling cylinder shut-off,e.g.
4 cylinder compressor on both cylinder heads:100% to approx.10%
Tandem compressors from 22,7m3/h to 303m3/h(50hz)
Approved parallel operation
VSD capacity control from 25 to 70HZ.Explanations see pages 7 and 8
ECOLINE compressors for frequency inverter operation up to 70 HZ

Specification

HP Compressor

Condenser
Surface
M2

Voltage Cooling capacity(W) Axial Fans
(V-Ph-Hz) Evaporating temperature(°C)
-35 -30 -25 -20 -15 N°x Diameter
2 2FES-2Y 16 380-3-50 1000 1420 1910 2480 3140 1 x 350
2 2EES-2Y 16 380-3-50 1280 1820 2450 3190 4050 1 x 400
2 2DES-2Y 16 380-3-50 1600 2240 2990 3870 4890 1 x 400
3 2CES-3Y 24 380-3-50 2110 2890 3810 4880 6120 2 x 350
3 4FES-3Y 24 380-3-50 2380 3170 4120 5250 6580 2 x 350
4 4EES-4Y 32 380-3-50 3010 4020 5240 6690 8390 2 x 400
5 4DES-5Y 42 380-3-50 3600 4800 6260 8000 10040 2 x 400
6 4CES-6Y 48 380-3-50 4220 5690 7480 9610 12120 2 x 400
8 4TES-9Y 64 380-3-50 4840 6740 9030 11780 15040 2 x 450
10 4PES-12Y 80 380-3-50 5040 7200 9830 13010 16790 2 x 450
12 4NES-14Y 96 380-3-50 6580 9140 12240 15950 20350 4 x 400
15 4HE-18Y 120 380-3-50 10070 13570 17720 22600 28350 4 x 400
20 4GE-23Y 160 380-3-50 12320 16290 21000 26550 33050 4 x 400
25 6HE-28Y 200 380-3-50 14800 19970 26100 33300 41750 4 x 400
30 6GE-34Y 240 380-3-50 18920 24850 31800 39950 49400 2 x 600
40 6FE-44Y 320 380-3-50 21900 29250 37750 47650 59100 2 x 600
Product name condensing unit
Compressor brand compressor
Refrigerant R404A
Power 3hp
Condenser  air cooled condenser
Compressor type semi-hermetic compressor
Number of fan motor 1fan motor
Fan motor diameter 400mm
Application  Cold Storage Room Freezer Room
Brand  KUB


Optional components:

Piston Open type
U type unit
V type unit
casade refrigeration unit
CSH Screw Rack unit
HSN Screw Rack unit

-20~+45℃ Intelligent Integrate Commercial Refrigeration Condensing Units 3HP R404a For Cold Room Storage KB030RLE 3



Our Services
A. Individuation & Customization

Refrigeration industry, cold storage engineering; Agriculture, food, restaurant, chemical industry; we can undertake designs according to customer's requirements.



B. Excellent warranty

KUB provides up to one year warranty period. If there is any product quality problems, we will return processing, and is responsible in the end.

We provide excellent service to solve your worries.



Shanghai KUB Refrigeration Equipment Co., Ltd is an advanced enterprise specializing in design,

manufacture and trade of refrigeration equipment.

Founded in 2000 We have adopted internationally advanced technology to meet all the different needs of our

diverse customers.

Main products include: box type & open type condensing units,air cooled,water cooled condensing units,

mono block split type condensing units, low temperature screw condensing units,compressor racks, industrial chillers,D-series air coolers,double side blowing air coolers,water defrosting air coolers, air cooled condenser,

tube-shell water cooled condensers, tube-shell evaporator and electrical control boxes,etc.

All of our units adopt world famous brand compressors such as KUB,Carrier,Carlyle , Copeland,

Emerson,Maneurop,Tecumseh,danfoss etc.,with excellent performance a beautiful appearance.

They are widely used in cold storage, hotels,industrial processes,medical industries, chemical industries,refrigerated trucks,vessel industries all other places where cold storage is needed.

Our products and solutions have been widely applied in the fast-growing Chinese market,providing tens of

thousands of industrial equipment in machinery,electronics,plastics, textile, food,medical,chemical industry andrenewable energy and related fields.

KUB is widely recognized and respected by manufacturers,technicians and end users in the industry.

We export our products all over the world to countries in locations such as Europe,Middle East,Southeast

Asia, Africa,etc. and we support our customers with high quality products and turnkey solutions.



Cold Room Compressor  Condensing Unit 4HE18Y 1





Packaging & Shipping

Cold storage refrigeration condensing air-cooled unit :

The company has advanced information network technology and excellent location, a sound management system and modern means of communication and multi-faceted services. We insist on everything from the actual needs of customers, the implementation of the entire transport monitoring service is available 24 hours a day. These are the goods on time, safe, efficient destination to provide effective protection.
