R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER

  • R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER
  • R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER
  • R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER
  • R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER
Place of Origin Shanghai, China (Mainland)
Brand Name KUB
Model Number SLKD-060/B1
Minimum Order Quantity 1 Piece/Pieces
Price US $1315 / Pieces | 100 Piece/Pieces (Min. Order)
Packaging Details plywood package
Delivery Time 10-15days
Payment Terms L/C, T/T, Western Union
Supply Ability 500 units per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Capacity(kW) 131 Weight(kg) 190
Size(mm) 1848*380 Equipped With Unit(HP) 60
Water Tube N-1/N-2(RC) ø 2-1/2" Inlet Tube ø(mm) 35
Outlet Tube ø(mm) 42 Refrigerant R134a • R404A • R507A • R407C • R22
High Light

hydraulic solenoid valve

,

digital temperature controller
Leave a Message
Product Description

Watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER



Shell and tube heat exchanger is one of KUB special pressure vessel equipment with special equipment manufacturing license issued by Administration of Quality and Technology Supervision of P.R.C. We select material, produce and inspect every piece of shell & tube heat exchangers strictly subject to requests of manufacturing license. This series of products contains: shell and tube condenser, sea water condenser, dry evaporator for single/two-stage compressor(with direct/U type copper pipes), receiver...etc. Capacity of this series covers from 8.3KW to 397.8KW, fitting for different refrigerant, such as R134a • R404A • R507A • R407C • R22.





Characteristics

●Production and inspection perform strictly according to；

●Use effective out whorl copper pipe, high heat exchange efficiency, compact size, light weight;

●Guaranteed quality; tightness examination up to 2.4MPa gas pressure before delivery;

●Pressure vessel equipped with "safe fusible plug",it can automatically melt when liquid temperature in the shell reach a certain degree to guarantee safety;

●Condenser end cap has water-drain device, to avoid tube damage caused by frozen water in cold winter.



Application

●Refrigeration industry, cold room project

●Agricultural, food, restaurant, chemical industry

●Central air conditioning



→Tailor-made for customers



Nomination



R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER 0



Single system



Model Equipped with unit(HP) Capacity(kW) Dimension and physical size (mm) Inlet & outlet tube ø(mm) Water tube N-1/N-2(RC) ø Weight(kg)
A A1 B C D E N-3 N-6
SLKD-003/B 3 8.3 827 700 168 500 280 100 12 16 1" 44
SLKD-005/B 5 12.5 827 700 168 500 280 100 12 22 1-1/2" 46
SLKD-008/B 8 19 927 800 168 600 280 100 16 22 1-1/2" 52
SLKD-010/B 10 23.7 1127 1000 168 800 280 100 16 28 1-1/2" 60
SLKD-015/B 15 36.9 1249 1100 219 900 330 100 19 28 2" 93
SLKD-020/B 20 43.4 1249 1100 219 900 330 100 19 28 2" 96
SLKD-025/B 25 50.4 1309 1160 219 960 330 100 22 35 2" 101
SLKD-030/B 30 59.2 1649 1500 219 1100 330 100 28 35 2" 116
SLKD-040/B 40 88.8 1621 1500 219 1100 330 100 28 42 2-1/2" 126
SLKD-070/B 70 154.3 1848 1700 273 1100 380 100 42 54 3" 205
SLKD-080/B 80 176.9 2098 1950 273 1200 380 100 42 54 3" 230
SLKD-005/B 5 13.3 1021 900 219 700 330 100 12 22 1-1/2" 58
SLKD-008/B1 8 19.7 1121 1000 219 800 330 100 16 22 1-1/2" 76
SLKD-010/B1 10 24.7 1121 1000 219 800 330 100 16 28 1-1/2" 78
SLKD-015/B1 15 36.9 1251 1100 273 900 380 100 19 28 2" 121
SLKD-020/B1 20 43.0 1358 1210 273 900 380 100 22 28 2" 124
SLKD-025/B1 25 50.3 1648 1500 273 1100 380 100 22 35 2" 142
SLKD-030/B1 30 59.2 1648 1500 273 1100 380 100 28 35 2" 146
SLKD-035/B1 35 71.0 1648 1500 273 1100 380 100 28 35 2-1/2" 151
SLKD-040/B1 40 88.7 1648 1500 273 1100 380 100 28 42 2-1/2" 160
SLKD-050/B1 50 100.6 1848 1700 273 1300 380 100 35 42 2-1/2" 176
SLKD-060/B1 60 130.7 1848 1700 273 1300 380 100 35 42 2-1/2" 190



Remark: pressure meter interface N-4: RC1/8"; safe fusible plug interface N-5: RC3/8"



R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER 1



Technical data of C series



Model Equipped with unit(HP) Capacity(kW) Dimension and physical size(mm)
A A1 B C D E
SLKD-070/C 70 154.4 2035 1700 325 1000 450 150
SLKD-080/C 80 177.1 2285 1950 325 1200 450 150
SLKD-090/C 90 200.2 2285 1950 325 1200 450 150
SLKD-100/C 100 223.9 2436 2100 325 1300 450 200
SLKD-120/C 120 263.3 2636 2300 325 1500 450 200
SLKD-130/C 130 284.3 2813 2400 377 1400 500 250
SLKD-140/C 140 303.2 2813 2400 377 1400 500 250
SLKD-150/C 150 320.8 2913 2500 377 1500 500 250
SLKD-160/C 160 338.1 2913 2500 377 1500 500 250
SLKD-180/C 180 355.3 2913 2500 377 1500 500 250
SLKD-200/C 200 397.8 3013 2600 377 1600 500 250



Remark: pressure gauge interface N-4: RC1/8 " ; safe fusible plug interface N-5: RC 3/8 "



Model Connection ø
N-6/Gas inlet (mm) N-3/Liquied outlet (mm) N-1/Water inlet (inch) N-2/Water outlet (mm) SV/Safe valve (inch)
SLKD-070/C 54 42 3" 3" Rc3/8"
SLKD-080/C 54 42 3" 3"
SLKD-090/C 54 42 3" 3"
SLKD-100/C 54 42 4" 4"
SLKD-120/C 54 42 4" 4"
SLKD-130/C 67 54 4" 4"
SLKD-140/C 67 54 4" 4"
SLKD-150/C 67 54 4" 4"
SLKD-160/C 67 54 4" 4"
SLKD-180/C 76 54 5" 5"
SLKD-200/C 76 54 5" 5"

Remark: safe valve is optional components;



Dimension &physical size of C series



R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER 2



Double system

Technical data



Model Equipped with unit(HP) Capacity(kW) Dimension and physical size(mm) Weight(kg)
L L1 L2 L3 B C D
SLKS-010/B 2x5 2x11.8 1130 500 90 100 168 800 280 65
SLKS-015/B 2x7.5 2x18.5 1252 550 90 100 219 900 330 75
SLKS-020/B 2x10 2x21.7 1252 550 90 100 219 900 330 86
SLKS-025/B 2x12.5 2x24.9 1412 630 100 100 219 1000 330 110
SLKS-030/B 2x15 2x29.6 1652 750 100 100 219 1200 330 140
SLKS-040/B 2x20 2x44.2 1752 800 150 100 219 1200 330 170
SLKS-050/B 2x25 2x49.7 1953 900 150 100 273 1300 380 210
SLKS-060/B 2x30 2x62.2 1953 900 150 100 273 1300 380 260
SLKS-070/B 2x35 2x74.6 1953 900 150 100 273 1300 380 300
SLKS-080/B 2x40 2x82.9 2153 1000 150 100 273 1500 380 340



Model Connection ø
RG/Gas inlet(mm) RL/Liquid outlet (mm) Win/Water inlet(inch) Wout/Water outlet (inch) SV/Safe valve(inch)
SLKS-010/B 16 12 1-1/2" 1-1/2" Rc3/8"
SLKS-015/B 22 16 2" 2"
SLKS-020/B 28 16 2" 2"
SLKS-025/B 28 16 2" 2"
SLKS-030/B 28 19 2" 2"
SLKS-040/B 28 22 2-1/2" 2-1/2"
SLKS-050/B 35 22 2-1/2" 2-1/2"
SLKS-060/B 35 28 2-1/2" 2-1/2"
SLKS-070/B 35 28 3" 3"
SLKS-080/B 42 28 3" 3"



Dimension of double system

R134a • R404A • R507A • R407C • R22 watercool condencer for 60 hp SHELL & TUBE WATER COOLED CONDENSER 3



Sea water cooled condenser
Technical data



Model Equipped with unit(HP) Capacity(kW) Dimension and physical size(mm)
A A1 B C D E
HSKD-005/B 5 13.3 1096 900 219 700 330 100
HSKD-008/B 8 19.7 1196 1000 219 800 330 100
HSKD-010/B 10 24.7 1196 1000 219 800 330 100
HSKD-015/B 15 36.9 1296 1100 273 900 380 100
HSKD-020/B 20 43.0 1406 1210 273 900 380 100
HSKD-025/B 25 50.3 1696 1500 273 1100 380 100
HSKD-030/B 30 59.2 1696 1500 273 1100 380 100
HSKD-035/B 35 71.0 1696 1500 273 1100 380 100
HSKD-040/B 40 88.7 1696 1500 273 1100 380 100
HSKD-050/B 50 100.6 1896 1700 273 1300 380 100
HSKD-060/B 60 130.7 1896 1700 273 1300 380 100



Remark : safe fusible plug interface N-5 : RC 3/8"



Model Connection ø
RG/Gas inlet(mm) RL/Liquid outlet (mm) Win/Water inlet(inch) Wout/Water outlet(inch) SV/Safe valve (inch)
HSKD-005/B 12 22 1-1/2" 1-1/2" Rc3/8"
HSKD-008/B 16 22 1-1/2" 1-1/2"
HSKD-010/B 16 28 1-1/2" 1-1/2"
HSKD-015/B 19 28 2-1/2" 2-1/2"
HSKD-020/B 22 28 2-1/2" 2-1/2"
HSKD-025/B 22 35 2-1/2" 2-1/2"
HSKD-030/B 28 35 2-1/2" 2-1/2"
HSKD-035/B 28 35 2-1/2" 2-1/2"
HSKD-040/B 28 42 2-1/2" 2-1/2"
HSKD-050/B 35 42 2-1/2" 2-1/2"



General drawing of dimension and physical sizes
