WHP11500AEDPC9EQ R410A the units of refrigerating system SHANGHAI HITACHI Heat pump water heater compressor
| Place of Origin | Shanghai, China (Mainland) |
|---|---|
| Brand Name | HITACHI |
| Certification | CCC |
| Model Number | WHP11500AEDPC9EQ |
| Minimum Order Quantity | 40 Piece/Pieces |
| Price | US $226 / Pieces | 80 Piece/Pieces (Min. Order) |
| Packaging Details | Plywood |
| Delivery Time | 3-7days |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 5000 units per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Condition | New | Type | Rotary |
|---|---|---|---|
| Power Source | AC Power | Lubrication Style | Oil-less |
| Voltage | 220-240V | Warranty | One Year |
| Color | Black | Cooling Method | Air Cooling |
| Name | R410a Compressor | Application | Refrigerator |
| High Light | refrigeration compressor for cold room,screw type compressor |
||
Product Description
WHP11500AEDPC9EQ SHANGHAI HITACHI Heat pump water heater compressor
| Model | WHP11500AEDPC9EQ | Refrigerant | R410A | Application | Heat pump water heater |
| Output | 2950W | Number of pallets | 40 | Original | Made in China |
Compressor parameter introduction
SUBJECT
Mod el W HP1 15 00 AE DPC 9E Q SP ECI FI CA TI ON W HP 11 50 0AE DP C9 EQ
PAGE: 1/30
1. SPECIFICATION OF THE MODEL
| Item | Spec | ||||
| 2.1 Model Type | WHP11500AEDPC9EQ | ||||
| 2.2 Power source input to inverter |
Rated voltage / Rated frequency/Phase 380V/50Hz/3(/) OR 220V/50HZ/1(/) ) |
||||
| 2 .3 Output | 2950(@3600 min-1) | ||||
| 2.4 Application | Heat pump water heater | ||||
| 2.5 Performance | |||||
| Item |
Standard Condition |
Rated Condition |
|||
| Rotational speed | 3400 min-1 | 3600 min-1 | |||
| Nominal Heating Capacity |
12650W |
12670W |
|||
| Motor input | 3080W | 3170W | |||
| Current | 13.0A | 13.0 | |||
| COP(see*) | 4.11 | 4.00 | |||
| Test Conditions | |||||
| Evaporating temp. | 10℃ | 7.2℃ | |||
| Condensing temp. | 55℃ | 54.4℃ | |||
| Liquid temp. entering expansion valve. |
46.7℃ |
46.1℃ |
|||
| Return gas temp. | 20℃ | 35℃ | |||
| Ambient temp. | 35℃ | 35℃ | |||
| Wind speed |
2m/s |
2m/s |
|||
| 2.6 Refrigerant | R410A |
| 2.7 Displacement | 30. 7 ml /rev |
| 2.8 Allowable frequency range | 900 ~ 7200 min-1 |
| 2.9 Oil | α 68HES-H or equivalent 1650 ± 20ml |
| 2.10 Allowable amount of refrigerant charge | Below 4500g |
| 2.11 Compressor cooling | Forced air |
| 2.12 Hermetic Terminal | |
| 2.13 Space volume of inner case | 2628cm 3 |
| 2.14 Compressor weight | 19. 10 kg incl. Oil |
|
2.15 Motor Type Insulation class |
Direct current brushless motor E class |
| 2.16 | 19.9Hz/21.7Hz/24.5Hz |
Rated Capacity and input are measured with HITACHI inverter circuit by secondary Refrigerant calorimeter Methods of JIS B8606 by Shanghai Hitachi Electrical Appliances Co., Ltd. Allowable capacity should be more than 95% of the rated capacity and allowable input should be less than 107% of rated motor input.
Specified inverter is linked up with compressor terminals . Applied voltage of this inverter should be voltage specified in this “compressor specification”. Alternating voltage should never be applied on terminals (for example:commercial alternating voltage of 1φ100V,200V,3φ200V).This is because that if applied alternating current the direct current motor will demagnetize.
The oil should be returned continuously to the compressor and the structure of the refrigerating system should not make oil stay in the system. The oil level in compressor should be satisfied with chart 2.If not keep the oil level, the shortage will occur, and influence the reliability of the compressor.(please check the oil level in the compressor with the sight glass which supplied form SHEC.
