made in china D Type Refrigeration Evaporator for cold room storage

Place of Origin Shanghai China
Brand Name KUB
Model Number DD-6/30
Minimum Order Quantity 1
Price negotiable
Packaging Details Carton
Supply Ability 50 units per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Refrigerant R22/R404A/507C Voltage 220V/1PH/50HZ
Horsepower 4HP Temperature -18°C
Warranty 1 Year Size 152*420*560mm
Weight 65kg
High Light

air fan cooler heat exchanger

,

low temperature evaporator

Leave a Message
Product Description

DD-6/30 6000W cooling capacity cube ice evaporator coolroom D type Unit Cooler Evaporator

made in china D Type Refrigeration Evaporator for cold room storage

Product Description

Use special intergral casting iron alloy ,having high rigidity and The sliding board designed with long-way type and equipped with balacing device of sliding board ,can guaran-tee running.



Model Cooling capacity Fan quantity and diameter cooling area Defrosting method
DD-6/30 6000w 2*400mm 30m² Electric defrosting

Model W   Nominal refrigeration volume

Area of cooling

(380V)Air cooler Defrosting electric heating tube mm Inlet mm Outlet
      W Power m³/h Air volume mm Diameter m Range kw Coll kw Drip Pan

DL-2.1/10 2100 10 80 1563 300 7 0.6 0.6 12 19
DD-1.4/7 1400 7         1×0.6 0.6
DJ-0.8/5 800 5         1×0.6 0.6
DL-3.1/15 3100 15 2×80 2×1563 300 7 0.9 0.9 12 19
DD-2.4/12 2400 12         1×0.9 0.9
DJ-1.3/8 1300 8         1×0.9 0.9
DL-4.1/20 4100 20 2×80 2×1563 300 7 1.3 1.3 12 19
DD-3/15 3000 15         1.3 1.3
DJ-1.8/10 1800 10         1.3 1.3
DL-5.2/25 5200 25 2×140 2×2290 350 7 2×1.2 1.2 12 22
DD-4.4/22 4400 22         2×1.2 1.2
DJ-2.1/15 2100 15         2×1.2 1.2
DL-8.3/40 8300 40 2×180 2×3400 400 9 2×1.4 1.4 16 25
DD-6/30 6000 30         2×1.4 1.4
DJ-4/20 4000 20         2×1.4 1.4
DL-11.5/55 11500 55 2×180 2×3400 400 9 2×1.4 1.4 16 25
DD-8/40 8000 40         2×1.4 1.4
DJ-6/30 6000 30         2×1.4 1.4
DL-16.7/80 16700 80 2×250 2×4800 450 9 2×1.5 1.5 19 38
DD-12/60 12000 60         5×1.5 1.5
DJ-8/40 8000 40         5×1.5 1.5
DL-22/105 22000 105 2×250 2×4800 450 9 2×1.5 1.5 19 38
DD-16/80 16000 80         5×1.5 1.5
DJ-11/15 11000 55         5×1.5 1.5
DL-25.8/125 25800 125 3×250 3×4800 450 9 2×2.1 2.1 19 38
DD-20/100 20000 100         5×2.1 2.1
DJ-14/70 14000 70         5×2.1 2.1
DL-33.6/160 33600 160 3×250 3×4800 450 9 2×2.4 2.4 19 38
DD-24/120 24000 120         5×2.4 2.4
DJ-17/85 17000 85         5×2.4 2.4
DL-38.7/185 38700 185 4×250 4×4800 450 9 2×3 3 25 50
DD-28/140 28000 140         5×3 3
DJ-20/100 20000 100         5×3 3
DL-44/210 44000 210 4×250 4×4800 450 9 2×3.2 3.2 25 50
DD-32/160 32000 160         5×3.2 3.2
DJ-23/115 23000 115         5×3.2 3.2
DL-52.9/260 52900 260 2×780 2×10820 600 12 5×2.7 2.7 25 50
DD-40/200 40000 200         8×2.7 2.7
DJ-28/140 28000 140         8×2.7 2.7
DL-67.2/330 67200 330 3×780 3×10820 600 12 5×3.3 3.3 25 50
DD-50/250 50000 250         8×3.3 3.3
DJ-34/170 34000 170         8×3.3 3.3
DL-85.6/450 85600 450 3×780 3×10820 600 12 5×3.5 3.5 25 50
DD-60/300 60000 300         8×3.5 3.5
DJ-42/210 42000 210         8×3.5 3.5
DL Type cooling fan nominal cooling capacity means:t=0℃,△T=T-T.=7℃,Fin spacing4.5mm.
DD Type cooling fan nominal cooling capacity means:t=-18℃,△T=T-T.=7℃,Fin spacing6mm.
DJ Type cooling fan nominal cooling capacity means:t=-25℃,△T=T-T.=7℃,Fin spacing9mm.
